HS-6100PM foam characteristics tester

The instrument is designed according to GB/T12579-90 and ASTMD892 standards to determine the foam characteristics of lubricating oil and avoid mechanical failure.

Main feature

1, liquid crystal display, menu click input command, high temperature accuracy, stable and reliable.

2, built-in gas source, automatically blow air for 5 minutes after constant temperature, automatic timing separation for 10 minutes.

The main technical parameters

1, high temperature range: room temperature ~ 100 ° C

2, low temperature range: 10 ~ 30 ° C

3, temperature control accuracy: ± 0.5 ° C

4, the number of test cups: 4 holes

5, flow meter regulating valve range: 16-160mL / min, 4 groups

6, gas source: built-in gas source, 3L / min

7, gas diffusion head: 3000 ~ 6000ml / min, under 2.45Kpa

8, power: AC220 ± 22V, 50 ± 1Hz

9, power: 2300W

10, Dimensions: 900 × 390 × 700mm (H × W × D)

11, weight: 10Kg
